Owner's Manual - Vehicle Usage Instructions

Vehicle "Power Cut" (Power is on, but the vehicle loses drive)

Battery dead
Motor overheating
Controller overheat
Battery overheating
Tipping power failure (cut power output after 3 seconds of vehicle tipping)
Power off of the foot brace (when the foot brace is supported, there is no power output by twisting the throttle handle)

*When the air switch is off, there is no power output by twisting the throttle knob.

Vehicle Power Reduction

1) When the battery power is less than 15%, the controller will reduce the output power to protect the battery.

* Due to the characteristics of the battery, the meter display may be inaccurate.

2) When the power is less than 5%, if there is a large load (such as urgent refueling or steep slope, etc.), the controller may enter under voltage protection and the vehicle will stop running. If you don't charge it in time, the battery may enter the over-discharge protection at any time (the battery enters the over-discharge protection can effectively protect the battery cell, and the charger needs to be reactivated after the over-discharge protection.

3) The controller overheats (when the operating temperature exceeds 95°C, the vehicle will reduce the power and enter ECO mode, and if the continuous overheating exceeds 105°C, the power output will be cut off).

4)Motor overheating (when the operating temperature exceeds 130°C, the vehicle will reduce power and enter ECO mode, if the continuous overheating exceeds 150°C, the power output will be cut off.)

Operating conditions

At temperatures below 0°C, the battery is equivalent to 80% of its daily capacity. Sports gear is not recommended When the temperature is higher than 40°C, it is recommended not to ride at full power for a long time.

Water Exposure Guidelines

The key electrical components of 79BlKE of-road motorcycles are designed with full consideration of the waterproof requirements in the normal riding environment, the wading depth does not exceed 20cm, and can not soak in water for along time, especially when the motor is at high temperature and cooled by water,the internal air shrinks, causing water absorption from the oil seal and cable to enter the interior, causing damage, The following are the waterproof levels of each component:
◆Battery and motor: IP67
◆Controller: IP67
◆Full connector: IP55
